SOLUS BOLT ACTION RIFLE SYSTEM

GETTING TO KNOW YOUR SOLUS CHASSIS & STOCK




The SOLUS Competition Chassis was designed to meld the body of a shooter with the action of a rifle. For these two systems to harmonically work together there was a high focus on both general ergonomics and adjustability to easily provide shooters with a tailored fit. Beyond ergonomics, the SOLUS Competition Chassis also emphasizes modularity, accommodating numerous different accessories—allowing for the firearm to be tailored to a multitude of different use cases.

Adjustable thumb rest, length of pull, cheek comb height, and recoil pad cant allow for the shooter to fit the chassis to their individual body. Full length Arca and M-LOK forend allow for the inclusion of many industry standard accessories and tripod mounts. An adjustable ambidextrous magazine catch allows for positive lockup with the many different AICS and AIAW detachable box magazines currently on the market.




SOLUS BOLT ACTION RIFLE SYSTEM

GETTING TO KNOW YOUR SOLUS CHASSIS & STOCK




The SOLUS Competition Chassis was designed to meld the body of a shooter with the action of a rifle. For these two systems to harmonically work together there was a high focus on both general ergonomics and adjustability to easily provide shooters with a tailored fit. Beyond ergonomics, the SOLUS Competition Chassis also emphasizes modularity, accommodating numerous different accessories—allowing for the firearm to be tailored to a multitude of different use cases.

Adjustable thumb rest, length of pull, cheek comb height, and recoil pad cant allow for the shooter to fit the chassis to their individual body. Full length Arca and M-LOK forend allow for the inclusion of many industry standard accessories and tripod mounts. An adjustable ambidextrous magazine catch allows for positive lockup with the many different AICS and AIAW detachable box magazines currently on the market.




SOLUS

TECH SPECS



SPECIFICATIONS

SOLUS Tech Specs

KEY ATTRIBUTES

  • Footprint: Remington 700 Short Action
  • Construction: 7075-T6 center section and stock, 6061 T-6 forend
  • Magazine Compatibility: AICS/AIAW
FEATURES

  • V-block bedding surface
  • Fully adjustable length of pull, cheek comb height, and recoil pad cant
  • M-LOK/Arca compatible forend
  • Adjustable thumb rest
  • Ambidextrous magazine release



SOLUS

TECH SPECS COMPETITION RIFLE



SPECIFICATIONS

SOLUS Tech Specs



KEY ATTRIBUTES

  • Action: SOLUS Short Action
  • Chassis: SOLUS Competition Chassis
  • Trigger: SOLUS Single Stage
  • Caliber: 6 Creedmoor, 6.5 Creedmoor, 308 WIN
  • Magazine: AICS/AIAW detachable box magazine


FEATURES

  • 60-degree bolt throw
  • Integral 20 MOA bias scope base
  • Adjustable cheek comb, length of pull, and recoil pad cant
  • M-LOK/Arca compatible forend


Chassis Adjustments

SOLUS

ADJUSTMENTS

To adjust the Length of Pull of the stock, unscrew the knob until the knob no longer turns. With the knob fully loosened, use one hand to depress and hold the spring-loaded knob. With the other hand, grasp the Length of Pull/Recoil Pad assembly and lengthen or shorten the stock’s length of pull to suit your needs. The length is adjustable in seven ¼” increments. The stock’s spring-loaded locking mechanism will engage on each of the seven recesses. Once the desired length has been obtained and the spring-loaded knob has engaged in a locked position, tighten the knob to complete the stock’s length of pull adjustment.

Adjusting the Comb Riser is accomplished in a similar process using the forward upper knob. After the knob is loosened, the adjustable comb can be raised or lowered. Depressing the knob is not required for the Comb Riser once in the desired position. Tightening the knob secures the riser in place.




SOLUS

ADJUSTMENTS

To adjust the Length of Pull of the stock, unscrew the knob until the knob no longer turns. With the knob fully loosened, use one hand to depress and hold the spring-loaded knob. With the other hand, grasp the Length of Pull/Recoil Pad assembly and lengthen or shorten the stock’s length of pull to suit your needs. The length is adjustable in seven ¼” increments. The stock’s spring-loaded locking mechanism will engage on each of the seven recesses. Once the desired length has been obtained and the spring-loaded knob has engaged in a locked position, tighten the knob to complete the stock’s length of pull adjustment.

Adjusting the Comb Riser is accomplished in a similar process using the forward upper knob. After the knob is loosened, the adjustable comb can be raised or lowered. Depressing the knob is not required for the Comb Riser once in the desired position. Tightening the knob secures the riser in place.


Chassis Adjustments

Chassis Adjustments

SOLUS

ADJUSTMENTS CONT.

Magazine Latch Height Adjustment

The magazine latch height can be adjusted to ensure correct retention and presentation of the magazine. To adjust, simply loosen the Locking Screw two full turns (see following image). Insert your magazine into the magazine well. Tighten the Height Adjustment screw to minimize magazine movement. Test by releasing the magazine a few times through depressing the magazine release. No binding should occur. If binding does occur or the magazine will not drop free, slowly back off the Height Adjustment Screw. Once satisfied with your adjustment, secure the Locking Screw. Use Vibra-Tite VC-3 or Loctite 222 to prevent loosening of the fasteners. Apply no more than 4 in/lbs of torque to the Locking Screw.

Adjustable Thumb Rest Installation

The adjustable thumb rest comes installed on the chassis, to adjust it to your desired position loosen the two #6-32 adjustment screws until you can move the thumb rest back and forth. There is .380” of adjustment frontwards and back. Once the desired position is achieved tighten the top screw to hold the thumb rest in place and apply a light coat of Loctite 222 and torque to no more than 3.5 in/lbs. Repeat process on top screw.




SOLUS

ADJUSTMENTS CONT.

Magazine Latch Height Adjustment

The magazine latch height can be adjusted to ensure correct retention and presentation of the magazine. To adjust, simply loosen the Locking Screw two full turns (see following image). Insert your magazine into the magazine well. Tighten the Height Adjustment screw to minimize magazine movement. Test by releasing the magazine a few times through depressing the magazine release. No binding should occur. If binding does occur or the magazine will not drop free, slowly back off the Height Adjustment Screw. Once satisfied with your adjustment, secure the Locking Screw. Use Vibra-Tite VC-3 or Loctite 222 to prevent loosening of the fasteners. Apply no more than 4 in/lbs of torque to the Locking Screw.

Adjustable Thumb Rest Installation

The adjustable thumb rest comes installed on the chassis, to adjust it to your desired position loosen the two #6-32 adjustment screws until you can move the thumb rest back and forth. There is .380” of adjustment frontwards and back. Once the desired position is achieved tighten the top screw to hold the thumb rest in place and apply a light coat of Loctite 222 and torque to no more than 3.5 in/lbs. Repeat process on top screw.


Chassis Adjustments


SOLUS

GENERAL QUESTIONS



What chassis/stocks can I use?
You can use any option that is inleted for a Remington 700.


Is the SOLUS chassis one piece?
The Solus chassis is three pieces the center section, handguard, and stock. Although it is not a one-piece design it maintains rigidity and the ability to customize features.


What material is the chassis?
6061-T6


What does Sub MOA mean?
Sub MOA means that the average group size is less than 1 minute of angle or 1.047" at 100 yards Often shooters will use Shooter minute of angle and round down to 1" at 100 yards.



SOLUS

GENERAL QUESTIONS



What chassis/stocks can I use?
You can use any option that is inleted for a Remington 700.


Is the SOLUS chassis one piece?
The Solus chassis is three pieces the center section, handguard, and stock. Although it is not a one-piece design it maintains rigidity and the ability to customize features.


What material is the chassis?
6061-T6


What does Sub MOA mean?
Sub MOA means that the average group size is less than 1 minute of angle or 1.047" at 100 yards Often shooters will use Shooter minute of angle and round down to 1" at 100 yards.


Aero Lifetime Warranty

SOLUS BOLT ACTION RIFLE SYSTEM

LIFETIME MANUFACTURER WARRANTY

We provide a lifetime warranty against manufacturing defects and damage caused by the normal use of our products. Aero Precision LLC will repair or replace any products that is has manufactured, sold, or distributed. This warranty does not cover defects or damage that are not the result of “normal use,” as determined by Aero Precision LLC in its full discretion, including but are not limited to defects and damage resulting from modification of the product, neglect or abuse of the product, improper transportation of the product, improper maintenance of the product, use of defective or improper ammunition, failure to follow the instructions in the product manual, use of the product with incompatible components, and criminal activity. To make a warranty or repair inquiry, contact Aero Precision’s customer service team by visiting aeroprecisionusa.com/contact and submitting a form. DO NOT send or ship products to Aero Precision for repair or replacement without first receiving authorization from Aero Precision’s customer service team. Failure to follow these instructions may void this warranty at Aero Precision’s discretion.

THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ANY AND ALL OTHER WARRANTIES, CONDITIONS AND REPRESENTATIONS, WHETHER WRITTEN, ORAL, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION ANY IMPLIED CONDITION, REPRESENTATION OR WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. THIS WARRANTY SHALL CONSTITUTE THE SOLE REMEDY OF THE PURCHASER OR USER OF THE PRODUCT, AND AERO PRECISION LLC SHALL NOT BE LIABLE FOR AN ALLEGEDLY DEFECTIVE OR DAMAGED PRODUCT EXCEPT TO REPAIR OR REPLACE IT IN ACCORDANCE WITH THIS WARRANTY. IN NO EVENT, TO THE EXTENT PERMITTED BY LAW, SHALL AERO PRECISION LLC BE LIABLE FOR CONSEQUENTIAL, CONTINGENT, INCIDENTAL, INDIRECT OR SPECIAL DAMAGES CAUSED OR ALLEGED TO BE CAUSED IN WHOLE OR IN PART BY THE NEGLIGENCE, TORT, STRICT LIABILITY, BREACH OF CONTRACT, BREACH OF WARRANTY, OR BREACH OF DUTY OF OR BY AERO PRECISION LLC.


Aero Lifetime Warranty


SOLUS BOLT ACTION RIFLE SYSTEM

LIFETIME MANUFACTURER WARRANTY

We provide a lifetime warranty against manufacturing defects and damage caused by the normal use of our products. Aero Precision LLC will repair or replace any products that is has manufactured, sold, or distributed. This warranty does not cover defects or damage that are not the result of “normal use,” as determined by Aero Precision LLC in its full discretion, including but are not limited to defects and damage resulting from modification of the product, neglect or abuse of the product, improper transportation of the product, improper maintenance of the product, use of defective or improper ammunition, failure to follow the instructions in the product manual, use of the product with incompatible components, and criminal activity. To make a warranty or repair inquiry, contact Aero Precision’s customer service team by visiting aeroprecisionusa.com/contact and submitting a form. DO NOT send or ship products to Aero Precision for repair or replacement without first receiving authorization from Aero Precision’s customer service team. Failure to follow these instructions may void this warranty at Aero Precision’s discretion.

THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ANY AND ALL OTHER WARRANTIES, CONDITIONS AND REPRESENTATIONS, WHETHER WRITTEN, ORAL, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION ANY IMPLIED CONDITION, REPRESENTATION OR WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. THIS WARRANTY SHALL CONSTITUTE THE SOLE REMEDY OF THE PURCHASER OR USER OF THE PRODUCT, AND AERO PRECISION LLC SHALL NOT BE LIABLE FOR AN ALLEGEDLY DEFECTIVE OR DAMAGED PRODUCT EXCEPT TO REPAIR OR REPLACE IT IN ACCORDANCE WITH THIS WARRANTY. IN NO EVENT, TO THE EXTENT PERMITTED BY LAW, SHALL AERO PRECISION LLC BE LIABLE FOR CONSEQUENTIAL, CONTINGENT, INCIDENTAL, INDIRECT OR SPECIAL DAMAGES CAUSED OR ALLEGED TO BE CAUSED IN WHOLE OR IN PART BY THE NEGLIGENCE, TORT, STRICT LIABILITY, BREACH OF CONTRACT, BREACH OF WARRANTY, OR BREACH OF DUTY OF OR BY AERO PRECISION LLC.



SOLUS Disclaimers

SOLUS

DISCLAIMERS

When using a firearm, always adhere to the 4 rules of firearms safety:

  1. Treat every firearm as if it is loaded.
  2. Always keep your firearm pointed in a safe direction.
  3. Keep your finger off the trigger until you have acquired a proper sight picture and are ready to fire.
  4. Be aware of your target and what is behind it.



SOLUS

DISCLAIMERS

When using a firearm, always adhere to the 4 rules of firearms safety:

  1. Treat every firearm as if it is loaded.
  2. Always keep your firearm pointed in a safe direction.
  3. Keep your finger off the trigger until you have acquired a proper sight picture and are ready to fire.
  4. Be aware of your target and what is behind it.
